MAGIC 85

Round Adjustable Recessed Downlight

MAGIC 85

LED COB Round Adjustable Recessed Downlight

The Magic series can meet different lighting design requirements. There are four kinds of cutout sizes, and the power is from 5W to 40W. It can also be used for adjustable wall washer lighting and accent lighting. The Magic series has a special optical design that greatly reduces the amount of uncomfortable light reflected by the reflector and improves the quality of light and pleasant visual experience. The Magic series has a unique structural design that makes it easy to be installed on the ceiling without damaging the ceiling itself. In addition, the Magic series can be easily replaced by different front covers without any tools.

Lighting Effects

Products Specification:: Type:LED COB Round Adjustable Recessed Downlight; Mechanical Performance:Fixed / Adjustable; Cut-Out:ø 85 mm; Beam Angle:8D 15D 25D 30D 36D 50D; Power:5W 8W 10W 12W 15W; CCT:2700K 3000K 4000K; Heat-Sink:Aluminum; Surface-Treatment:Plating; Weight:0.57kg; Remarks:IP44 for visible body of fitting after installation，not available for using with honeycomb louver

Line Drawing:

General Features:

Accessories :

Reflector Color:

Frame Color:

Select your Model No:
*Please log in before selecting your Model No

Power(W)

Power(W)
5W
8W
12W
15W

Beam Angle

Beam Angle
15°
25°
38°
50°

CRI

CRI
RA>90

Color

Color
2700K
3000K
4000K

Dimming type

Dimming type
1-Non Dim
2-Phase dimming
3-0-10V dimming
4-DALI dimming

Finish

Finish
02-Black
01-White

Reflector

Reflector
1-White
4-Champagne gold

IP Rating

IP Rating
44-IP44

Accessory

Accessory
1-Honeycomb louver
4-Linear lens

Model No
Luminaire lumen（LM）
Power (W)
Beam Angle
CRI
Color
Specification
IES
DWG
manual
Favorite

Model No: DR00102-05159027; DR00102-05159030; DR00102-05159040; DR00102-05259027; DR00102-05259030; DR00102-05259040; DR00102-05389027; DR00102-05389030; DR00102-05389040; DR00102-05509027; DR00102-05509030; DR00102-05509040; DR00102-08159027; DR00102-08159030; DR00102-08159040; DR00102-08259027; DR00102-08259030; DR00102-08259040; DR00102-08389027; DR00102-08389030; DR00102-08389040; DR00102-08509027; DR00102-08509030; DR00102-08509040; DR00102-12159027; DR00102-12159030; DR00102-12159040; DR00102-12259027; DR00102-12259030; DR00102-12259040; DR00102-12389027; DR00102-12389030; DR00102-12389040; DR00102-12509027; DR00102-12509030; DR00102-12509040; DR00102-15159027; DR00102-15159030; DR00102-15159040; DR00102-15259027; DR00102-15259030; DR00102-15259040; DR00102-15389027; DR00102-15389030; DR00102-15389040; DR00102-15509027; DR00102-15509030; DR00102-15509040

Luminous Flux (LM): 367LM; 386LM; 434LM; 375LM; 395LM; 436LM; 383LM; 403LM; 453LM; 373LM; 393LM; 439LM; 551LM; 580LM; 654LM; 572LM; 602LM; 670LM; 588LM; 619LM; 694LM; 569LM; 599LM; 672LM; 784LM; 825LM; 926LM; 964LM; 1015LM; 1081LM; 1002LM; 1054LM; 1161LM; 985LM; 1037LM; 1112LM; 896LM; 944LM; 1074LM; 1143LM; 1203LM; 1276LM; 1178LM; 1240LM; 1354LM; 1139LM; 1199LM; 1308LM

Power (W): 5W; 5W; 5W; 5W; 5W; 5W; 5W; 5W; 5W; 5W; 5W; 5W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 8W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 12W; 15W; 15W; 15W; 15W; 15W; 15W; 15W; 15W; 15W; 15W; 15W; 15W

Beam Angle: 15°; 15°; 15°; 25°; 25°; 25°; 38°; 38°; 38°; 50°; 50°; 50°; 15°; 15°; 15°; 25°; 25°; 25°; 38°; 38°; 38°; 50°; 50°; 50°; 15°; 15°; 15°; 25°; 25°; 25°; 38°; 38°; 38°; 50°; 50°; 50°; 15°; 15°; 15°; 25°; 25°; 25°; 38°; 38°; 38°; 50°; 50°; 50°

CRI: RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90; RA>90

Color: 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K; 2700K; 3000K; 4000K
