LINNOU 25

3W Fixed Asymmetrical Light/ Direct Light

LINNOU 25

Small & Delicate Great Practicality

LINNOU 25

Small & Delicate Great Practicality

Creative design with small, thin and deep style. LINNOU lamp's overall minimum size is only Ø 60 * H72mm. LINNOU is named for its compact shape, which saves the hole opening size when installing, effectively solves the problem that the big hole opening on the ceiling may destroy skyline integrity of the space. In addition, the delicate lamps can be lively coordinated with the reflector which has a variety of color. Designers can choose different reflector according to the comprehensive color of ceiling and space, to present both practicability and beauty.
Through the clever and ultra-thin design of adjustable lamps, and the minimum height of lamps is controlled in the range of 75 mm. In satisfying the inside height 80 mm under ceiling, it maximally saves the indoor space. And in view of the small size light's new spring design, under the condition of meet the polarization of 30 degrees, it can effectively solve the problem of installation requirements on thickness 8 ~ 20 mm of ceiling. Design innovation and practicality is presented incisively and vividly in the research and development and application of the LINNOU series downlight.

Lighting Effects

Products Specification:
Type:3W Fixed Asymmetrical Light/ Direct Light
Cut-out:ø 25 mm
Beam Angle:21D 31D
Power:3W
CCT:2700K 3000K 4000K
Line Drawing:
General Features:

Accessories :
Reflector Color:
Frame Color:

Select your Model No:

*Please log in before selecting your Model No

Power(W)
  • Power(W)
  • 3 W
Beam Angle
  • Beam Angle
  • 31°
  • 21°
  • asymmetrical
CRI
  • CRI
  • Ra>90
  • Ra>80
Color
  • Color
  • 4000 K
  • 3000 K
  • 2700 K
  • Model No

  • Luminous Flux (LM)

  • Power (W)

  • Beam Angle

  • CRI

  • Color

  • Specification

  • IES

  • Favorite

Model No

7811101-03319040

7811101-03319030

7811101-03319027

7811101-03218040

7811101-03219030

7811101-03219027

7811501-03XX9040

7811501-03XX9030

7811501-03XX9027

Luminous Flux (LM)

244 LM

228 LM

228 LM

180 LM

150 LM

150 LM

287LM

287 LM

266 LM

Power (W)

3 W

3 W

3 W

3 W

3 W

3 W

3 W

3 W

3 W

Beam Angle

31°

31°

31°

21°

21°

21°

asymmetrical

asymmetrical

asymmetrical

CRI

Ra>90

Ra>90

Ra>90

Ra>80

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Color

4000 K

3000 K

2700 K

4000 K

3000 K

2700 K

4000 K

3000 K

2700 K

Specification
IES
Favorite
