POYO 80

Wall mounted up and down downlight

POYO 80

Looking forward to being shining, like the jade is waiting for carving.

POYO is surface-mounted light on the ceiling or wall, the internal driving design hid the driver perfectly. A wide optional range of appearance, the whole series is included small, medium and large sizes. The adjustable structure has a horizontal rotation of 350 degrees
and a vertical angle of 30 degrees to achievethe precise adjustment of the illuminated object. From 5W to 80W, a complete range of beam angle supports the application from small space to high space

Lighting Effects

Products Specification:
Type:Wall mounted up and down downlight
Beam Angle:23D 32D 40D 50D
Power:5W 8W 10W 15W
CCT:2700K 3000K 4000K
Heat-Sink:Forging Aaluminium
Surface-Treatment:powder coating
Weight:0.85 kg
Remark:Available for Up lighting
Line Drawing:
General Features:

Accessories :
Reflector Color:
Frame Color:

Select your Model No:

*Please log in before selecting your Model No

Power(W)
  • Power(W)
  • 2x5W
  • 2x8W
Beam Angle
  • Beam Angle
  • 27°
  • 35°
  • 40°
  • 50°
CRI
  • CRI
  • Ra>90
Color
  • Color
  • 2700K
  • 3000K
  • 4000K
Dimming type
  • Dimming type
  • 1-Non Dim
  • 3-0-10V dimming
  • 4-DALI dimming
Finish
  • Finish
  • Black
  • White
  • Grey
Reflector
  • Reflector
  • Black
IP Rating
  • IP Rating
  • 65-IP65
Accessory
  • Accessory
  • N/A
  • Model No

  • Luminaire lumen(LM)

  • Power (W)

  • Beam Angle

  • CRI

  • Color

  • Specification

  • IES

  • DWG

  • manual

  • Favorite

Model No

DW00803-10279027

DW00803-10279030

DW00803-10279040

DW00803-10359027

DW00803-10359030

DW00803-10359040

DW00803-10409027

DW00803-10409030

DW00803-10409040

DW00803-10509027

DW00803-10509030

DW00803-10509040

DW00803-16279027

DW00803-16279030

DW00803-16279040

DW00803-16359027

DW00803-16359030

DW00803-16359040

DW00803-16409027

DW00803-16409030

DW00803-16409040

DW00803-16509027

DW00803-16509030

DW00803-16509040

Luminous Flux (LM)

734LM

772LM

824LM

728LM

768LM

820LM

674LM

710LM

762LM

550LM

578LM

628LM

1184LM

1246LM

1326LM

1174LM

1236LM

1316LM

1086LM

1142LM

1226LM

890LM

938LM

1008LM

Power (W)

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x5W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

2x8W

Beam Angle

27°

27°

27°

35°

35°

35°

40°

40°

40°

50°

50°

50°

27°

27°

27°

35°

35°

35°

40°

40°

40°

50°

50°

50°

CRI

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Ra>90

Color

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

2700K

3000K

4000K

Specification
IES
DWG
manual
