ECO 180
Round Fixed Recessed Downlight
ECO 180
This product would be discontinued since 2023-5-2
ECO is a series of products with high cost performance.Economic, flexible and pragmatic are its most prominent features. It has rich choises for size and power:3inch(cutout φ95mm)， 4inch (cutout φ130mm)， 5inch (cutout φ160mm)，6inch (cutout φ180mm)，8 inch (cutout φ220 mm), which gives a better lighting effect than what you have expected in various spaces . As a lighting fixture that provides basic lighting,its unique ultra-thin shell design (the maximum height of the lamp is 65mm) makes it possible to use flexibly within the limited ceiling space，thereby reducing construction difficulty. At the same time, the right -emitting surface has no dark areas, no light spots, high uniformity, and high lamp efficiency，It is the first choice for providing basic lighting for simple and large spaces.
ECO is a series of products with high cost performance.Economic, flexible and pragmatic are its most prominent features. It has rich choises for size and power:3inch(cutout φ95mm)， 4inch (cutout φ130mm)， 5inch (cutout φ160mm)，6inch (cutout φ180mm)，8 inch (cutout φ220 mm), which gives a better lighting effect than what you have expected in various spaces . As a lighting fixture that provides basic lighting,its unique ultra-thin shell design (the maximum height of the lamp is 65mm) makes it possible to use flexibly within the limited ceiling space，thereby reducing construction difficulty. At the same time, the right -emitting surface has no dark areas, no light spots, high uniformity, and high lamp efficiency，It is the first choice for providing basic lighting for simple and large spaces.
Lighting Effects
- Products Specification:
- Type:Round Fixed Recessed Downlight
- Cut-Out:Ø 180mm
- Power:17W 22W 34W
- Beam Angle:100D
- Weight:0.91kg
- CCT:2700K 3000K 4000K
- Heat-Sink:Aluminum
- Surface-Treatment:Plating
- Line Drawing:
- General Features:
- Accessories :
- Reflector Color:
- Frame Color:
Select your Model No:
*Please log in before selecting your Model No
Power(W)
- Power(W)
- 17W
- 22W
- 34W
Beam Angle
- Beam Angle
- 100°
CRI
- CRI
- Ra>90
Color
- Color
- 2700K
- 3000K
- 4000K
Dimming type
- Dimming type
- 1-Non Dim
- 3-0-10V dimming
- 4-DALI dimming
Finish
- Finish
- 01-White
- 02-Black
Reflector
- Reflector
- nothing
IP Rating
- IP Rating
- 20-IP20
Accessory
- Accessory
- nothing
Model No
Luminaire lumen（LM）
Power (W)
Beam Angle
CRI
Color
Specification
IES
DWG
manual
Favorite
- Model No
18111E1-17A19027
18111E1-17A19030
18111E1-17A19040
18111E1-22A19027
18111E1-22A19030
18111E1-22A19040
18111E1-34A19027
18111E1-34A19030
18111E1-34A19040
- Luminous Flux (LM)
1335LM
1363LM
1390LM
1891LM
1930LM
1968LM
2844LM
2903LM
2961LM
- Power (W)
17W
17W
17W
22W
22W
22W
34W
34W
34W
- Beam Angle
100°
100°
100°
100°
100°
100°
100°
100°
100°
- CRI
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
Ra>90
- Color
2700K
3000K
4000K
2700K
3000K
4000K
2700K
3000K
4000K
